XSW2-835

Specifiche Tecniche

System
Modulation : Wideband FM
Frequency Range A: 548 to 572 MHz B : 614 to 638 MHz
Switching Bandwidth : Up to 24 MHz
Frequencies : Adjustable in 25-kHz steps
8 frequency banks, each with up to 12 factory-preset channels
Signal to Noise Ratio : ≥ 103 dBA
Total Harmonic Distortion (THD) : ≤ 0.9%
Temperature Range : Operation: 32 to 104°F (0 to +40°C)
Storage: -4.0 to 158°F (-20 to +70°C)
Transmitter Synchronization : 2.4 GHz, low power OQPSK (only active during synchronization)

Receiver
Principle of Operation : Double superheterodyne
Diversity Method : True diversity
Sensitivity : < 3 µV at 52 dBA rms S/N at (peak deviation) Frequency Response : 50 Hz to 16 kHz (-3 dB) Maximum AF Output Voltage : At peak deviation, 1 kHz AF 1/4" (6.3 mm) Jack Socket (Unbalanced): +6 dBu XLR Socket (Balanced): +12 dBu At peak deviation, 1 kHz AF) Adjustment Range : Audio: 40 dB, adjustable in 5-dB steps Power Supply : Nominal Input: 100 to 240 VAC 50/60 Hz Input Current: 200 mA (Max.) Nominal Output: 12 VDC 300 mA Squelch : Adjustable from 3 dBμ V to 28 dBμ V (combined with pilot tone) Line/Mic Level : 20 dB, switchable Housing Material : Rugged metal housing Dimensions (W x H x D) : 200 x 42 x 127 mm Weight : 680 g Transmitter
RF Output Power : 10 mW
AF Frequency Response : 80 Hz to 16 kHz
Power Supply : 2 x AA size batteries, 1.5 V
Operating Time : Approximately 10 hours
Microphone Type : Dynamic
Input Sensitivity : Capsule: 1.5 mV/Pa
Polar Pattern : Cardioid
Sensitivity Adjustment Range: 0 to -30 dB, adjustable in 10-dB steps
Housing Material : Rugged ABS housing
Dimensions (L x Diam) : 260 x 50 mm approximate
Weight : 245 g approximate
